Yüksek Hız Anti-Keşif ve Anti-Keskin Nişancı Sistemi

FinderPro-X Deployable Counter-Reconnaissance and Anti-Sniper System

FinderPro-X Deployable Counter-Reconnaissance and Anti-Sniper System
FinderPro-X Deployable Counter-Reconnaissance and Anti-Sniper System
Anti Keşif ve Anti Keskin Nişancı Sistemleri

FinderPro-X Deployable Counter-Reconnaissance and Anti-Sniper System

Ürün Açıklaması:

The FinderPro-X deployable counter-reconnaissance and anti-sniper system can be configured for mobile setup or fixed installation according to different application scenarios. It uses active laser detection to identify optical observation devices nearby, provides high-definition target images and precise geographic coordinates, and can perform laser interference when necessary. The system consists of the main unit, mounting components, junction box, ruggedized computer, and other parts, with multiple optional functional modules available.

Ücretsiz Teklif Alın

Ürün Tanıtımı

FinderPro-X is designed for counter-reconnaissance and anti-sniper protection in regional defense scenarios.

Through active laser detection, the system searches designated areas, detects optical observation equipment, and determines target direction.

The main unit can include the target detection subsystem, follow-up imaging subsystem, laser interference / dazzling subsystem, optional laser warning subsystem, optional gunshot detection array, optional laser damage subsystem, high-speed turntable, and display-control equipment.

Uygulama senaryoları

  • Yüksek Hız Anti-Keşif ve Anti-Keskin Nişancı Sistemi

    Eşlik Güvenliği

  • Yüksek Hız Anti-Keşif ve Anti-Keskin Nişancı Sistemi

    Yerinde Güvenlik

  • Yüksek Hız Anti-Keşif ve Anti-Keskin Nişancı Sistemi

    Anahtar Alanlarda Anti-Keskin Nişancı Koruması

  • Yüksek Hız Anti-Keşif ve Anti-Keskin Nişancı Sistemi

    Operasyonlar Sırasında Anti-Keşif ve Karşı Saldırı

Ürün Özellikleri ve Teknik Şartnameler

Target Detection Subsystem

Scans the designated area with the high-speed turntable and quickly detects targets through active laser detection to determine their direction.

Follow-Up Imaging Subsystem

Under the guidance of the target detection subsystem, it images the target area during high-speed scanning to help identify the nature of the threat target.

Laser Interference / Dazzling Subsystem

Can perform green-light interference against targets, suppressing hostile observation and aiming, and can also dazzle the target so that its detector cannot work properly.

Laser Warning Subsystem Optional

Can detect ranging lasers and illuminating lasers, calculate direction, and provide warning.

Laser Damage Subsystem Optional

Can irradiate threat targets with a high-power laser to damage their electro-optical detectors.

Gunshot Detection Array Optional

Can process received gunshot signals to determine the shooting position.

Teknik Parametreler

Parametre Şartname Parametre Şartname
Arama Kapsamı 360° azimuth, -20° ~ +70° elevation Arama Hızı 360°/s azimuth speed, elevation angle range 8°
Detection Distance Range Minimum detection distance ≤50 m; maximum detection distance ≥2000 m for devices with aperture not less than 50 mm Tespit Olabilirliği ≥95%
Yanlış Alarm Oranı ≤10% Search-to-Interference Switching Time ≤3 s
Interference Laser Wavelength 530 nm Target Geographic Positioning Accuracy Better than 20 m for a 1 km target, integrated longitude, latitude and altitude
Lazer Menzil Mesafesi 30 m ~ 3000 m Laser Warning Optional Wavelength range 1 μm ~ 1.6 μm, angular resolution 45°



Uygulama etkileri

  • FinderPro-X Deployable Counter-Reconnaissance and Anti-Sniper System
  • FinderPro-X Deployable Counter-Reconnaissance and Anti-Sniper System
